Highlights
Model: SMR381-254/5BLK
1.Laser Tracker Reflector/Spherically Mounted Reflective
2.Metal Sphere Diameter: 38.1mm (1.5inch)
3.Sphere Roundness: ±0.002~0.005mm
4.Prism Aperture: 25.40mm (1inch)
5.Silver-coated Prism Accuracy: 5",w. BLK Flared Ring
6.Prism Constant: +17.5mm (Leica); -16.90mm(abs.)
7.Optics Centering: ±0.12~0.2mm
8.Compatible with all present Laser Tracker Systems
| Quantity: | |
|---|---|
SMR381-254/5BLK
Geomaster
9031809090
Specifications & Features
Model: SMR381-254/5BLK
1.Retro-reflective Prism (Corner Tube Prism)
1)Accuracy (Beam Deviation): 5"(Arc second)
2)Mini Prism Diameter: 25.4mm (1 inch)
3)Optics Centering ±0.12~0.2mm
4)Prism Constant: -16.9mm (absolute, non-Leica System); +17.5mm (Leica System)
5)Optical Glass K9-BK7
6)Silver-coated
7)Measuring Range: >50m
2.Metal Sphere (Prism Holder)
1)Sphere Diameter: 38.1mm (1.5inch)
2)Roundness Error (Sphericity): ±0.002~0.005mm
3)Hardened Surface,440C Stainless Steel
4)Black large-format Protective Ring (Flared wide-angled Ring),non-removable
Features
Model: SMR381-254/5BLK
1.Specially designed Reflective Sphere (Spherically Mounted Reflective, SMR) for Laser Trackers, Robotic Total Stations, ScanStations, MultiStations.
2.Compatible with all existing Laser Tracker Systems such as API,Faro,Leica,Hexagon,Trimble...
3.Corner Cube Prism made of high quality Optical Glass K9-BK7
4.Prism Accuracy 5"; 2" and 3" for option
5.Prism-coating available: Aluminum-coated, Copper-coated,Silver-coated
6.Precisely processed mini Prism, shockproof and waterproof
7.Metal Sphere: Stainless Steel, galvanized Steel and Blacking anodizes are available
8.Different-colored Prism Protective Ring available: Black Ring (BLK),Red Ring (RRR)
9.Magnetic Base/Support (with Centering Pin) is available
10.Customization services are available
1)SMR127-78: Sphere Dia: 12.7mm (0.5inch); Prism Dia: 7.87mm (0.31inch)
2)SMR222-127: Sphere Dia: 22.22mm (7/8inch); Prism Dia:12.7mm (0.5inch)
3)SMR300-178: Sphere Dia: 30.0mm; Prism Dia:17.8mm
4)SMR381-254: Sphere Dia: 38.1mm (1.5inch); Prism Dia: 25.4mm (1inch)
5)SMR450-254: Sphere Dia: 45.0mm; Prism Dia: 25.4mm
6)SMR500-254: Sphere Dia: 50.0mm; Prism Dia: 25.4mm
Note: Any updating would be subject to change without prior notice.
