Model: AL13/G-GY
1.Traverse Tribrach Adapter
2.Topon-style Prism Adapter
3.w.Optical Plummet
4.Plate Bubble: 60"/2mm
5.Compatible w. all Prism & GPS Tribrachs
6.Compatible w. all 24.9mm bayonet-based Surveying Acc.
| Quantity: | |
|---|---|
AL13/G-GY
Geomaster
90159000
Specifications & Features
Model: AL13/G-GY
1.New Topcon-style Traverse Tribrach Adapter for traversing and precise setting-up
2.Equipped with Twist-focusing Optical Plummet
(1)Magnification: 2.5x
(2)Focusing Range: 0.5-15m
(3)Plummet accuracy: ≦1mm at 1.5m
(4)Reflector Centering Accuracy: ≦1.5mm
3.Adjustable Height: 0mm
4.w.adjustable Plate Bubble: 60"/2mm
5.w.Bayonet Holder (ID:25mm),compatible with all 24.9mm (O.D.) bayonet-based Surveying Accessories like
Geomaster Prism Holders & Targets (AKZ series)...
6.Precision-machined rotating Axis, fitting all standard three-prong forced-centering Prism & GPS Tribrachs such as
Geomaster AJ13 series...
7.Colors a/v: Topcon Yellow; Leica Green (pale or dark),Sokkia Grey,Black
8.Customization service available
Note:Any updating would be subject to change without prior notice.
