Highlights
Model: CTP103-25F/ORG
1.Geomaster Contractor’s Tripod (CTP103)
2.Heavy-duty Aluminum Tripod
3.Height Range: 104-163cm (41-64")
4.Square Legs & Flat Triangular Head (F)
5.Dual Locks: Quick Clamps & Side Twist Locks
6.Dual Locks & Central Screw Color: Orange (ORG)
7.Central Screw Thread 5/8" w.Hook for Plumb Bob
8.Anti-skidding Chains & Shoulder Carrying Straps
9.For Theodolites,Robotic Total Stations,Laser Scanners
| Quantity: | |
|---|---|
CTP103-25F/ORG
Geomaster
90159000
Specifications & Features
Model: CTP103-25F/ORG
1.Geomaster heavy-duty Aluminum Surveying Tripod CTP103, ideal for most heavy-weight Surveying
and Construction Instruments such as Electronic Theodolites,Digital Theodolites, Optical Theodolites, Reflectorless Total Stations,Robotic Total Stations, ScanStations,3D Laser Scanners, Laser Trackers,
LiDAR Scanners
2.Height Range: 104-163cm (41-64")
3.Head Type: Flat Triangular (F)
4.Head Size: 160mm (OD)
5.Head Bore: 67.5mm (ID)
6.Orange (ORG) Central Connecting Screw,Quick-release Clamps and Side Twist Locks7.Square Legs
offering sturdy support and desired working heights
8.Square Leg Lock Style: Dual Locks (Top Quick-release Clamps+Bottom Side Twist Lock) for long
secure holding and stable supporting
9.Galvanized anti-skidding Security Chains preventing tripods from sliding on slippery grounds
10.Metal pointed tip-toe for hard, slippery, soft, wet and rugged surfaces
11.Central Connecting Screw with 5/8" Thread and Hook for Plumb Bob
12.Robust poly-webbing Shoulder Strap for easy carrying and transport
13.Available Colors: Black(BLK),Gray(GRY),Green(GRN),Orange(ORG),Yellow(YEL)
14.Tripod Floor (Security Stand) SST14-600 available for option
Note: Any updating would be subject to change without prior notice.
