Highlights
Model: D3-50 (LDM50)
1.Geomaster Laser Distance Measure
2.Laser Measure up to 50m with ±2mm
3.Large-format & LED-Backlit LCD
4.Data Memory up to 50 Records
5.Water-proof and dust-proof IP54
6.Measurements: Area/Volume, Single/Continuous, Angle/Pythagorean...
| Quantity: | |
|---|---|
D3-50 (LDM50,50m)
Geomaster
9015900090
Features
Model: D3-50 (LDM50)
1.Distance measurement (0.05m up to 50m)
2.Area measurement
3.Volume measurement
4.Pythagorean measurement
5.Single measurement
6.Continuous measurement
7.Addition/Subtraction
8.Min/Max measurement
9.Angle Measurement (±90°)
10.Measurement Reference: Front, Rear
11.With Tilting e-Sensor
12.Beeping Warning
13.Water-proof, dust-proof
Specifications
Model: D3-50 (LDM50)
1.Distance Measurement
1)Measuring Range (indoor): 0.05-50m
2)Accuracy (in door): ±2.0mm
3)Minimum Reading: 1mm
4)Measuring Units: m/mm or ft/in
5)Measuring Time: 7 times per second
2.Data Display
1)Illuminated (LED-back-lit) LCD
2)Display Capacity: 4 Lines; Size: 2.4"
3.Data Memory
up to 50 Records
4.Laser Source
1)Laser Diode,Class II, 635nm, <1mw
2)Laser auto-off: after 30 seconds
5.Power Supply
1)Alkaline Battery: LR6 (AA), 2´1.5v
2)Battery Life: up to 5000 Measurements
3)Auto Power-off: after 150secs
6. Waterproof and Dust-proof
IP54
7.Ambient Temperature
1)Operating Temperature: 0°C ~＋40°C
8.Standard Outfit
Main Unit, EVA Holster, Lanyard, English-version User Manual
Note: Any updates may be subject to change without prior notice.
