Highlights
Model: TSR30.0-17.8/5
1.Geomaster Total Station Reflector (TSR)
2.Spherically Mounted Reflective (SMR)
3.Metal Sphere Diameter: 30mm (1.18inch)
4.Metal Sphere Roundness: ±0.002~0.005mm
5.Prism Aperture:17.8mm (0.7inch)
6.Silver-coated Prism Accuracy (Beam Deviation): ≦5"
7.For Robotic Total Stations, ScanStations,MultiStations
| Quantity: | |
|---|---|
TSR30.0-17.8/5
Geomaster
9015900090
Specifications & Features
Model: TSR30.0-17.8/5-GDN
1.Metal Sphere (Prism Holder)
1)Sphere Diameter: 30mm (1.18inch)
2)Roundness Error (Sphericity): ±0.002~0.005mm
3)Hardened Surface,440C Stainless Steel
4)N.W.: 85g (the whole set)
2.Retro-reflective Prism (Corner Tube Prism)
1)Mini Prism Diameter: 17.8mm (0.7 inch)
2)Accuracy (Beam Deviation): ≦5"; 3" available
3)Prism Constant: -16.9mm (Absolute); +17.5mm (Leica System)
4)Quality Optical Glass K9-BK7
5)Silver-coated
6)Measuring Range: up to 1000m
Note: Any updating would be subject to change without prior notice.
